• Compact design
• Low operating torque
• SS316 Body &Wetted parts & 17/4PH-Stem material provide better corrosive resistance
• Anti blow-out proof stem design
• PTFE packing with PEEK gland provide positive leak free sealing
• Re adjustable packing for long life
• Bi directional flow capability
• Supply to NACE MR 0175 / ISO 15156, if required
• Top panel mounting with lock nut provision provided.
• 2x M6 Threaded top panel mounting option also provided.
• 2 x Side panel mounting hole provided
• Safety weep hole for all pressure connection area

Medium pressure Tube OD end connection.

Tube OD Inch (mm) | Port thread Inch (mm) | Orifice size

1/4(6.35) | 7/16 - 20 | 0.110(2.80)
3/8(9.53) | 9/16 - 18 | 0.204(5.20)
9/16(14.3) | 13/16 - 16 | 0.252(6.40)

• Body & Wetted parts – SS 316 / SS316L
• Stem – 17/4 ph
• PTFE packing with PEEK gland
• Seat - PEEK
• O Ring – Viton

- 10°C to 150°C ( -14°F to 302°F )

20000 psi Max ( 1379 Bar Max)

100% Hydro testing using water. Shell & Seat- 1.1Times of WP

EN10204 – 3.1 Certification will be provided if required
